AUTOMATIC SLOTTING MACHINE
Features:
- COMPLETELY AUTO FUNCTIONAL WITH ONE PUSH START BUTTON.
- HIGH EFFICIENCY "DUST JET" TYPE VACCUM SYSTEM FOR DUST AND CHIP COLLECTION.
- IN BUILT HMI TO ACCESS AND RECORD ALL THE DATA.
- ADVANCE SAFETY FEATURES ADDED TO PREVENT ACCIDENTS AND MSHAPS.
- NO DEPENDENCY ON SKILLED LABOUR.
- HIGH END PRODUCTION.
| MODEL | BST-ASM-40-110 | BST-ASM-50-200 | BST-ASM-75-250 | BST-ASM-110-315 | BST-ASM-200-400 | BST-ASM-400-650 |
|---|---|---|---|---|---|---|
| PIPE RANGE | 40-110MM | 50-200MM | 75-250MM | 110-315MM | 200-400MM | 400-600MM |
| CONECTING LOAD | 9.3KW | 15KW | 15KW | 18.6KW | 22KW | 22KW |
| MAIN MOTOR | 7.5HP | 15HP | 15HP | 20HP | 25HP | 25HP |
| PIPE LENGTH | 3/6 METER | 3/6 METER | 3/6 METER | 3/6 METER | 3/6 METER | 3/6 METER |
| CUTTING INDEXING | 2-3-5 SIDE (OPTIONAL) | 3-5-6 SIDE (OPTIONAL) | 3-5-6 SIDE (OPTIONAL) | 3-4-5-6-7 SIDE | 3-4-5-6-7 SIDE | 3-4-5-6-7-8 SIDE |
| CUTTING SLOT WIDTH | 0.2-1.5MM | 0.3-2MM | 0.3-2MM | 0.5-3MM | 0.5-3MM | 0.5-3MM |
| CUTTING STOCK | 250MM | 300MM | 350MM | 400MM | 400MM | 400MM |
| BLOWER | 3HP | 3HP | 3HP | 3HP | 3HP | 3HP |
